PAPER CI FLEXOGRAPHIC PRINTNG MACHINE

PAPER CI FLEXOGRAPHIC PRINTNG MACHINE

CHCI-J Series

The paper ci flexographic printing machine is a highly advanced and efficient printing option designed to meet the needs of modern printing establishments. it has revolutionized the printing process to create high-quality prints with unmatched precision and accuracy.The paper ci flexographic printing machine is also highly versatile and can print on a wide range of substrates, making it an ideal choice for printing on various packaging materials such as paper, films, and labels.

TECHNICAL SPECIFICATIONS

Model CHCI-600J CHCI-800J CHCI-1000J CHCI-1200J
Max. Web Width 650mm 850mm 1050mm 1250mm
Max. Printing Width 600mm 800mm 1000mm 1200mm
Max. Machine Speed 250m/min
Printing Speed 200m/min
Max. Unwind/Rewind Dia. Φ 800mm/Φ1200mm/Φ1500mm(Special size can be customized)
Drive Type Gear drive
Plate thickness Photopolymer plate 1.7mm or 1.14mm (or to be specified)
Ink water based / slovent based / UV/LED
Printing length (repeat) 350mm-900mm (Special size can be customized)
Range Of Substrates Films; Paper; Non-Woven; Aluminium foil; Laminates
Electrical supply Voltage 380V. 50 HZ.3PH or to be specified
  • Machine Features

    The CI flexographic printing machine is an amazing piece of equipment that has revolutionized the way we print. It is a cutting-edge technology that has made printing faster, more efficient. Here are some of the features of the CI flexographic printing machine that make it so incredible: 1. High-quality printing: The CI flexographic printing machine produces high-quality prints that are sharp and vibrant, making your images pop. 2. Speedy printing: The machine can print rolls of paper at up to 250 meters per minute. 3. Flexibility: The CI flexo printing machine can print on a vast range of materials, including paper, plastic, and more. This means that it’s an ideal solution for printing labels, packaging, and other products. 4. Low wastage: The machine is designed to use minimal ink and reduce material wastage. This means that you can reduce your printing costs and make your production process more environmentally friendly.

  • High efficiencyHigh efficiency
  • Fully automaticFully automatic
  • Eco-friendlyEco-friendly
  • Wide range of materialsWide range of materials
  • 样品-03
    2
    3
    4
    5
    样品-02

    Sample display

    CI flexo printing press has a wide range of application materials and is highly adaptable to various materials, such as transparent film, non-woven fabric, paper, etc.
